1/4 - 4 INCH Threaded 3 Piece Full Port. Ball Valves 1000PSI

Model#: BT-3AKBACK TO LIST

  • full port 3 piece ball valve
    Model#: BT-3AK

Stainless steel or Carbon Steel Body and ball and stem

  • Valve pressure rating 1000 psi 69 bar working pressure,
  • Max temperature rating 400°F, Full port, Blowout-proof stem, Locking lever handle Option, Threaded end connections to customer’s requirement .
  • Size range ¼" to 4"

THREAD ENDS CONNECTION



  • Ball Valve 3PC 1000PSI
  • Investment Casting
  • Pressure: 1000 PSI(PN63)
  • Floating Ball
  • Connection End: ASME B1.20.1 BS21.DIN2999/259,ISO228-1,JIS B 0203,ISO7/1
  • Material: Stainless Steel CF8,CF8M,1.4408,Carbon Steel WCB,1.0619
  • Size :1/4"~4"
  • Blow-Out Proof Stem
  • Fluid: Water, Gas, Oil
  • Pressure Test Per API598
  • Sample Purchase.
  • OEM / ODM Product.
